1999 – 2006 Arctic Cat ZR,ZL,ZRT Heat Exchanger -Right Tube

2001 ZR 800

Heat Exchanger – Right Tube
0716-920

ASSEMBLIES WHERE 0716-920 IS USED
1999 ZR 500 (99Z5A) – COOLING ASSEMBLY
1999 ZR 500 EFI (99Z5C) – COOLING ASSEMBLY
1999 ZR 500 EFI LE – BLACK (99Z5G) – COOLING ASSEMBLY
1999 ZR 500 EFI LE – GREEN (99Z5D) – COOLING ASSEMBLY
1999 ZR 500 EFI LE – PEARL (99Z5H) – COOLING ASSEMBLY
1999 ZR 500 LE – BLACK (99Z5E) – COOLING ASSEMBLY
1999 ZR 500 LE – GREEN (99Z5B) – COOLING ASSEMBLY
1999 ZR 500 LE – PEARL (99Z5F) – COOLING ASSEMBLY
1999 ZR 600 (99Z6A) – COOLING ASSEMBLY
1999 ZR 600 EFI (99Z6C) – COOLING ASSEMBLY
1999 ZR 600 EFI LE – BLACK (99Z6E) – COOLING ASSEMBLY
1999 ZR 600 EFI LE – GREEN (99Z6D) – COOLING ASSEMBLY
1999 ZR 600 EFI LE – WHITE (99Z6F) – COOLING ASSEMBLY
1999 ZR 600 LE – BLACK (99Z6J) – COOLING ASSEMBLY
1999 ZR 600 LE – GREEN (99Z6G) – COOLING ASSEMBLY
1999 ZR 600 LE – PEARL (99Z6K) – COOLING ASSEMBLY
1999 ZR 700 (99Z7A) – COOLING ASSEMBLY
2000 POWDER SPECIAL 2K (S2000ZXDMCUSG) – COOLING ASSEMBLY
2000 THUNDERCAT BLACK (S2000TCLAAUS) – COOLING ASSEMBLY
2000 THUNDERCAT GREEN (S2000TCLAAUSG) – COOLING ASSEMBLY
2000 ZL 440 (S2000ZLBCAUSB) – COOLING ASSEMBLY
2000 ZL 500 (BLACK) (S2000ZLCCAUSB) – COOLING ASSEMBLY
2000 ZL 500 (SOLAR FLARE) (S2000ZLCCAUSG) – COOLING ASSEMBLY
2000 ZL 500 EFI (S2000ZLCEFUSB) – COOLING ASSEMBLY
2000 ZL 550 ESR (S2000ZLCERUS) – COOLING ASSEMBLY
2000 ZL 580 EFI ESR (S2000ZLDERUS) – COOLING ASSEMBLY
2000 ZL 600 (S2000ZLDAAUS) – COOLING ASSEMBLY
2000 ZL 600 EFI (S2000ZLDCAUSB) – COOLING ASSEMBLY
2000 ZL 700 (S2000ZLFCAUSB) – COOLING ASSEMBLY
2000 ZR 2K (S2000ZXDCAUSG) – COOLING ASSEMBLY
2000 ZR 500 (S2000ZRCCAUS) – COOLING ASSEMBLY
2000 ZR 500 EFI (S2000ZRCEFUS) – COOLING ASSEMBLY
2000 ZR 600 (S2000ZRDCAUS) – COOLING ASSEMBLY
2000 ZR 600 BLAIR MORGAN SIGNATURE EDITION (S2000ZRDSEUSG) – COOLING ASSEMBLY
2000 ZR 600 EFI (S2000ZRDEFUSG) – COOLING ASSEMBLY
2000 ZR 600 EFI – LE (S2000ZRDELUSG) – COOLING ASSEMBLY
2000 ZR 600 EFI – LE REVERSE (S2000ZRDENUSG) – COOLING ASSEMBLY
2000 ZR 700 (BLACK) (S2000ZRFAAUSB) – COOLING ASSEMBLY
2000 ZR 700 (GREEN) (S2000ZRFAAUSG) – COOLING ASSEMBLY
2000 ZR 700 – LE (S2000ZRFLEUSG) – COOLING ASSEMBLY
2000 ZR 700 – LE (REVERSE) (S2000ZRFWRUSG) – COOLING ASSEMBLY
2000 ZRT 600 (BLACK) (S2000ZTDAAUSB) – COOLING ASSEMBLY
2000 ZRT 600 (GREEN) (S2000ZTDAAUSG) – COOLING ASSEMBLY
2000 ZRT 800 (BLACK) (S2000ZTHAAUSB) – COOLING ASSEMBLY
2000 ZRT 800 (GREEN) (S2000ZTHAAUSG) – COOLING ASSEMBLY
2001 THUNDERCAT (S2001TCLCAUST) – COOLING ASSEMBLY
2001 ZL 500 EFI ESR (S2001ZLCERUST) – COOLING ASSEMBLY
2001 ZL 550 (S2001ZLCCAUSB) – COOLING ASSEMBLY
2001 ZL 550 (ESR) (S2001ZLCDEUSB) – COOLING ASSEMBLY
2001 ZL 600 EFI (S2001ZLDEFUSB) – COOLING ASSEMBLY
2001 ZL 600 EFI (ESR) (S2001ZLDERUST) – COOLING ASSEMBLY
2001 ZL 800 (ESR ILLUSION) (S2001ZLHERUST) – COOLING ASSEMBLY
2001 ZL 800 (ESR) (S2001ZLHERUSB) – COOLING ASSEMBLY
2001 ZR 500 (S2001ZRCCAUSG) – COOLING ASSEMBLY
2001 ZR 500 EFI (S2001ZRCEFUSG) – COOLING ASSEMBLY
2001 ZR 500 EFI (ESR) (S2001ZRCERUST) – COOLING ASSEMBLY
2001 ZR 600 (S2001ZRDCAUSG) – COOLING ASSEMBLY
2001 ZR 600 EFI (S2001ZRDEFUSG) – COOLING ASSEMBLY
2001 ZR 600 EFI LE (S2001ZRDLEUSB) – COOLING ASSEMBLY
2001 ZR 600 VEV (S2001ZRDAAUSG) – COOLING ASSEMBLY
2001 ZR 800 (S2001ZRHCAUSG) – COOLING ASSEMBLY
2001 ZR 800 LE (S2001ZRHLEUSB) – COOLING ASSEMBLY
2001 ZRT 600 (S2001ZTDCAUSB) – COOLING ASSEMBLY
2001 ZRT 600 LE (S2001ZTDLEUSG) – COOLING ASSEMBLY
2001 ZRT 800 (S2001ZTHCAUSB) – COOLING ASSEMBLY
2001 ZRT 800 LE (S2001ZTHLEUSG) – COOLING ASSEMBLY
2002 4-STROKE TRAIL (S2002ACFLCUSG) – COOLING ASSEMBLY
2002 THUNDERCAT (S2002TCLWRUSB) – COOLING ASSEMBLY
2002 ZL 500 (S2002ZLCAAUSB) – COOLING ASSEMBLY
2002 ZL 550 (S2002ZLCCAUSB) – COOLING ASSEMBLY
2002 ZL 550 (ESR) (S2002ZLCERUSM) – COOLING ASSEMBLY
2002 ZL 600 EFI (S2002ZLDAAUSB) – COOLING ASSEMBLY
2002 ZL 600 EFI (ESR) (S2002ZLDEEUSM) – COOLING ASSEMBLY
2002 ZL 600 EFI SS (S2002ZLDSEUSB) – COOLING ASSEMBLY
2002 ZL 600 EFI SS (BLACK ESR) (S2002ZLDEAUSB) – COOLING ASSEMBLY
2002 ZL 600 EFI SS (BLACK) (S2002ZLDSSUSB) – COOLING ASSEMBLY
2002 ZL 600 EFI SS (ORANGE ESR) (S2002ZLDEAUSO) – COOLING ASSEMBLY
2002 ZL 600 EFI SS (ORANGE) (S2002ZLDSSUSO) – COOLING ASSEMBLY
2002 ZL 800 EFI ESR (S2002ZLHEEUSM) – COOLING ASSEMBLY
2002 ZL 800 EFI SS BLACK (S2002ZLHSSUSB) – COOLING ASSEMBLY
2002 ZL 800 EFI SS ORANGE (S2002ZLHSSUSO) – COOLING ASSEMBLY
2002 ZR 500 (S2002ZRCCAUSG) – COOLING ASSEMBLY
2002 ZR 500 CC (BLACK) (S2002ZRCLEUSB) – COOLING ASSEMBLY
2002 ZR 500 CC (GREEN) (S2002ZRCLEUSG) – COOLING ASSEMBLY
2002 ZR 600 (S2002ZRDCAUSG) – COOLING ASSEMBLY
2002 ZR 600 EFI (S2002ZRDEFUSG) – COOLING ASSEMBLY
2002 ZR 600 EFI CC (BLACK) (S2002ZRDELUSB) – COOLING ASSEMBLY
2002 ZR 600 EFI CC (GREEN) (S2002ZRDELUSG) – COOLING ASSEMBLY
2002 ZR 800 (S2002ZRHCAUSG) – COOLING ASSEMBLY
2002 ZR 800 CC (BLACK) (S2002ZRHCCUSB) – COOLING ASSEMBLY
2002 ZR 800 CC (GREEN) (S2002ZRHCCUSG) – COOLING ASSEMBLY
2002 ZR 800 EFI (S2002ZRHEFUSG) – COOLING ASSEMBLY
2002 ZR 800 EFI CC (BLACK) (S2002ZRHELUSB) – COOLING ASSEMBLY
2002 ZR 800 EFI CC (GREEN) (S2002ZRHELUSG) – COOLING ASSEMBLY
2002 ZRT 600 (S2002ZTDCAUSB) – COOLING ASSEMBLY
2003 4-STROKE TRAIL (S2003ACFLCUSG) – COOLING ASSEMBLY
2003 ZL 550 (S2003ZLCLCUSB) – COOLING ASSEMBLY
2003 ZL 550 (ESR BLACK) (S2003ZLCERUSB) – COOLING ASSEMBLY
2003 ZL 550 (ESR SILVER) (S2003ZLCERUSM) – COOLING ASSEMBLY
2003 ZL 600 EFI (S2003ZLDEFUSB) – COOLING ASSEMBLY
2003 ZL 600 EFI (ESR BLACK) (S2003ZLDEEUSB) – COOLING ASSEMBLY
2003 ZL 600 EFI (ESR SILVER) (S2003ZLDEEUSM) – COOLING ASSEMBLY
2003 ZL 600 EFI SS (BLACK) (S2003ZLDSSUSB) – COOLING ASSEMBLY
2003 ZL 600 EFI SS (ESR BLACK) (S2003ZLDEAUSB) – COOLING ASSEMBLY
2003 ZL 600 EFI SS (ESR SILVER) (S2003ZLDEAUSM) – COOLING ASSEMBLY
2003 ZL 600 EFI SS (SILVER) (S2003ZLDSSUSM) – COOLING ASSEMBLY
2003 ZL 800 EFI ESR (ESR BLACK) (S2003ZLHEEUSB) – COOLING ASSEMBLY
2003 ZL 800 EFI ESR (ESR SILVER) (S2003ZLHEEUSM) – COOLING ASSEMBLY
2003 ZL 800 EFI SS (BLACK) (S2003ZLHSSUSB) – COOLING ASSEMBLY
2003 ZL 800 EFI SS (SILVER) (S2003ZLHSSUSM) – COOLING ASSEMBLY
2003 ZR 800 EFI (BLACK) (S2003ZRHEFUSB) – COOLING ASSEMBLY
2003 ZR 800 EFI (GREEN) (S2003ZRHEFUSG) – COOLING ASSEMBLY
2003 ZR 800 EFI SNO PRO (BLACK) (S2003ZRHEPUSB) – COOLING ASSEMBLY
2003 ZR 800 EFI SNO PRO (GREEN) (S2003ZRHEPUSG) – COOLING ASSEMBLY
2003 ZR 900 (BLACK) (S2003ZRJCBUSB) – COOLING ASSEMBLY
2003 ZR 900 (GREEN) (S2003ZRJCBUSG) – COOLING ASSEMBLY
2003 ZR 900 EARLY BUILD (S2003ZRJCAUSG) – COOLING ASSEMBLY
2003 ZR 900 SNO PRO (BLACK) (S2003ZRJCSUSB) – COOLING ASSEMBLY
2003 ZR 900 SNO PRO (GREEN) (S2003ZRJCSUSG) – COOLING ASSEMBLY
2004 T660 TURBO TRAIL BLACK (S2004ACFTSUSB) – COOLING ASSEMBLY
2004 T660 TURBO TRAIL TAUPE (S2004ACFTSUSU) – COOLING ASSEMBLY
2004 ZR 900 BLACK-GREEN (S2004ZRJCAUSG) – COOLING ASSEMBLY
2004 ZR 900 BLACK-RED (S2004ZRJCAUSR) – COOLING ASSEMBLY
2004 ZR 900 EFI BLACK-GREEN (S2004ZRJEFUSG) – COOLING ASSEMBLY
2004 ZR 900 EFI BLACK-RED (S2004ZRJEFUSR) – COOLING ASSEMBLY
2004 ZR 900 EFI SNO PRO BLACK-GREEN (S2004ZRJEPUSG) – COOLING ASSEMBLY
2004 ZR 900 EFI SNO PRO BLACK-RED (S2004ZRJEPUSR) – COOLING ASSEMBLY
2004 ZR 900 SNO PRO BLACK-GREEN (S2004ZRJCSUSG) – COOLING ASSEMBLY
2004 ZR 900 SNO PRO BLACK-RED (S2004ZRJCSUSR) – COOLING ASSEMBLY
2005 T660 TURBO BLACK (S2005ACFTBUSB) – COOLING ASSEMBLY
2005 T660 TURBO ST GREEN (S2005ACFTBUSG) – COOLING ASSEMBLY
2005 T660 TURBO ST RED (S2005ACFTBUSR) – COOLING ASSEMBLY
2005 ZR 900 BLACK (S2005ZRJCAUSB) – COOLING ASSEMBLY
2005 ZR 900 EFI BLACK (S2005ZRJEFUSB) – COOLING ASSEMBLY
2005 ZR 900 EFI GREEN (S2005ZRJEFUSG) – COOLING ASSEMBLY
2005 ZR 900 EFI SNO PRO BLACK (S2005ZRJEPUSB) – COOLING ASSEMBLY
2005 ZR 900 EFI SNO PRO GREEN (S2005ZRJEPUSG) – COOLING ASSEMBLY
2005 ZR 900 GREEN (S2005ZRJCAUSG) – COOLING ASSEMBLY
2005 ZR 900 SNO PRO BLACK (S2005ZRJCSUSB) – COOLING ASSEMBLY
2005 ZR 900 SNO PRO GREEN (S2005ZRJCSUSG) – COOLING ASSEMBLY
2006 PANTHER 660 TRAIL (S2006PAFLCUSB) – COOLING ASSEMBLY
2006 T660 TURBO ST BLACK (S2006ACFTSUSB) – COOLING ASSEMBLY
2006 T660 TURBO ST GREEN (S2006ACFTSUSG) – COOLING ASSEMBLY
2006 T660 TURBO TRAIL BLACK (S2006ACFTBUSB) – COOLING ASSEMBLY
2006 T660 TURBO TRAIL LE BLACK (S2006ACFTRUSB) – COOLING ASSEMBLY
2006 ZR 900 EFI BLACK (S2006ZRJEFUSB) – COOLING ASSEMBLY
2006 ZR 900 EFI SNO PRO BLACK (S2006ZRJEPUSB) – COOLING ASSEMBLY
2007 PANTHER 660 TRAIL (S2007PAFLCUSB) – COOLING ASSEMBLY
2007 T660 TURBO TRAIL BLACK (S2007ACFTBUSB) – COOLING ASSEMBLY
2007 T660 TURBO TRAIL GREEN LE (S2007ACFTRUSG) – COOLING ASSEMBLY
